FPC：柔性電路板(柔性PCB): 簡稱"軟板", 又稱"柔性線路板", 也稱"軟性線路板、撓性線路板"或"軟性電路板、撓性電路板", 英文是"FPC PCB"或"FPCB,Flexible and Rigid-Flex"。
FFC柔性扁平電纜 Flexible Flat Cable(FFC)是一種用PET絕緣材料和極薄的鍍錫扁平銅線，通過高科技自動化設備生產線壓合而成的新型數據線纜，具有柔軟、隨意彎曲折疊、厚度薄、體積小、連接簡單、拆卸方便、易解決電磁屏蔽(EMI)等優點。
Electrical Current Rating : 0.2 Ampere Insulation Resistance : 500 MΩ Min Dielectric Withstanding : 200 V Contact Resistance : 20 mΩ Max | Mechanical Contact Retention : 0.8N/Pin Min Durability : 20 Cycles |
Material Housing : High Temperature Plastic UL 94V-0 Cover : High Temperature Plastic UL 94V-0 Contact : Phosphor Bronze Peg : Brass | Plating Contact : Gold or Tin plated on contact area Nickel plated overall Peg : Tin under plated Nickel overall |
| Environment Characteristics Operating temperature : -25℃ to +85℃ |
只需一個電話即可與我們的專家團隊溝通，86-755-2979 2280
UTE Group is established in Dec .of 2005 and professional on connectors R&D ,manufacturing and sales.
